iSound FBS
1- Built-in 24Bit A/D, D/A conversion; 32-bit DSP processor.
2- High-speed floating-point digital audio processor.
3- Sub-Band and Echo cancellation technology.
4- The working mode of fully automatic operation, easy to use.
5- Intelligent dynamic environment noise reduction technology, improve the signal-to-noise ratio and improve sound quality.
6- Intelligent control technology, improve the distance of picking up sound and obtain clear, continuous, and stable voice signal.
7- 2.0-inch color display screen, the status display of each function of the equipment is concise and clear.

Datasheet

Model iSound FBS
Name Feedback Suppressor
Microphone Input 2-XLR and 2-TRS, Balanced or unbalanced input
Input Impedance Balanced: 20K, Unbalanced: 10K
Mic input sensitivity -5.5dBu(@Out=0dBu)
Dynamic Range >109dB (A-weighted)
Distortion < 0.1%
Feedback suppression frequency response +/- 1dB (20Hz to 13KHz)
Direct frequency response +/- 0.5dB (20Hz to 13KHz)
Dynamic Gain Boost 6-8dB
Working power supply AC110-240V/50-60Hz
Power consumption <20W
Size 480x220x44 (mm)
Weight 2.5Kg

Download

  • INFOBIT iSound FBS User manual V2.0.pdf

    0.33M 21-05-2024
